Calpeda GQV Submersible Sewage and Drainage Pump with Horizontal Threaded Port (MADE IN ITALY)

₱32,188.00

⏳ Exclusive Discount. Sale ends in {timer}

CONSTRUCTION Single-impeller submersible pumps, with free-flow (vortex) impeller. GQS: with vertical threaded delivery port G 2”.  GQV: with horizontal G 2” or G 2”1/2 threaded delivery port and with DN 50...

Model: GQVm (1-Phase)

GQVm (1-Phase)
GQV (3-Phase)

Capacity: 0.75 HP

0.75 HP
1 HP
1.2 HP
1.5 HP
2 HP

Duck Foot Coupling: with QDC

with QDC
without QDC
Add to Wishlist
People are viewing this right now

Guaranteed Safe Checkout

INSTALLMENT payment is available via BILLEASE (Click for Details).

Manufacturer Partner & Authorized Reseller. Click to View More:

Calpeda
Description
CONSTRUCTION
Single-impeller submersible pumps, with free-flow (vortex) impeller.
GQS: with vertical threaded delivery port G 2”.
GQV: with horizontal G 2” or G 2”1/2 threaded delivery port and with DN 50 or DN 65 flanged delivery port.
Connections:  threaded ports ISO 228/1.
threaded ports NPT (ANSI/ASME B1.20.1) on request
Double mechanical shaft seal with interposed oil chamber, to protect against dry-running.

APPLICATIONS
For domestic or industrial waste water, dirty water with solids up to 50 mm (65 mm for GQV 65) grain size, for liquids which are compatible with the pump materials.
For draining rooms or or emptying tanks.
Extraction of water from ponds, streams or pits and for rainwater collection.

OPERATING CONDITIONS
Liquid temperature +5 °C to +35° C.
pH value: 6-11.
Maximum immersion depth: 5 m.
Minimum immersion depth: 275 mm (355 mm for GQV 65).
Continuous duty (with submerged motor).

MOTOR
  • 2-pole induction motor, 60 Hz (n ≈ 3450 rpm).
  • GQS, GQV: three-phase 220 V;  or three-phase 380 V;  or three-phase 440 V. Cable: H07RN-F,  length 10 m. *WITHOUT FLOAT SWITCH
  • GQSm, GQVm: single-phase 110 V, 127 V, 220 V, with float switch, with thermal protector only 220V. Incorporated capacitor  only 220V. Cable: H07RN-F, length 10 m, with plug CEI-UNEL 47166.
  • Insulation class F.
  • Protection IP X8 (for continuous immersion)
  • Triple impregnation humidity-proof dry winding.
  • Constructed in accordance with: EN 60034-1; EN 60335-1, EN 60335-2-41.



MATERIALS:
Component Material
Pump casing Cast iron GJL 200 EN 1561
Impeller Cast iron GJL 200 EN 1561
Motor jacket Chrome-nickel steel 1.4301 EN 10088 (AISI 304)
Jacket cover Chrome-nickel steel 1.4301 EN 10088 (AISI 304)
Casing cover Chrome-nickel steel 1.4301 EN 10088 (AISI 304)
Handle Polypropylene (with frame in AISI 304)
Shaft Cr-Ni steel 1.4301 EN 10088 (AISI 304)
Mechanical seal: upper / lower Ceramic alumina/Carbon/NBR
Seal lubrication oil Oil for food/pharmaceutical machinery


PUMP MODEL

 MOTOR

KW

HP
GQVm (50-8-60) 0.55 0.75
GQVm (50-9-60) 0.75 1
GQVm (50-11-60) 0.9 1.2
GQVm (50-13-60) 1.1 1.5
GQVm (50-15-60) 1.5 2
GQV (50-8-60) 0.55 0.75
GQV (50-9-60) 0.75 1
GQV (50-11-60) 0.9 1.2
GQV (50-13-60) 1.1 1.5
GQV (50-15-60) 1.5 2




DOWNLOADS

GQV: Product Catalogue

GQV: Product Instructions
