Calpeda META Self-Priming Booster Set with Built-in Pressure Transducer, Check Valve, Pressure Vessel, and On-Pump Inverter (MADE IN ITALY)
⏳ Exclusive Discount. Sale ends in {timer}
CONSTRUCTONSelf-priming booster set with built in frequency converter. MÈTA is a plug and play solution, the pump is equipped with an integrated pressure transducer, an integrated check valve and a built-in...
Guaranteed Safe Checkout
INSTALLMENT payment is available via BILLEASE (Click for Details).
Manufacturer Partner & Authorized Reseller. Click to View More:
Self-priming booster set with built in frequency converter.
MÈTA is a plug and play solution, the pump is equipped with an integrated pressure transducer, an integrated check valve and a built-in pressure vessel.
The Vsd controls the start and stop of the pump and allows to keep a constant pressure.
Boosting sets with 2 pumps
Suction and delivery manifolds in stainless steel AISI 304.
Connections for the installation of one G 1" connection pressure vessel
APPLICATIONS
For water supply systems.
For domestic use, for garden use and irrigation.
FEATURES
- integrated frequency converter
- built-in pressure vessel
- high efficiency asynchronous motor
- motor power control
- programmable re-start pressure
- no hydraulic losses due to the measuring devices
- voltage and current control
- monitoring of maximum starting current
PROTECTIONS
- dry-run protection
- detects the presence of air in the pump casing
- overload control and overheating motor control
- pump blockage
- power supply control
- starts per hour control
- detects small leakages in the system
OPERATING CONDITIONS
- Liquid temperature: 0 °C to +35 °C.
- Ambient temperature up to 40° C.
- Maximum permissible pressure in the pump casing: 8 bar.
- Continuous duty.
MOTOR
- 2-pole induction motor.
- Nominal speed 4500 rpm
- - Motor: variable speed
- Frequency: 60 Hz
- Single-phase with thermal protector.
- Cable: H07RN8-F, 3G1,5 mm2, length 1,5 m, with plug
- CEI-UNEL 47166.
- Insulation class F.
- Protection IP X4.
- Constructed in accordance with EN 60034-1, EN 60335-1, EN 60335-2-41.
| Component | Material |
|---|---|
| Pump casing | Cr-Ni steel 1.4301 EN 10088 (AISI 304) |
| Casing cover | Cr-Ni steel 1.4301 EN 10088 (AISI 304) |
| Pump shaft | Cr-Ni steel 1.4305 EN 10088 (AISI 303) |
| Suction casing | PPO-GF20 (Noryl) |
| Stage casing | PPO-GF20 (Noryl) |
| Impeller | Cr-Ni steel 1.4301 EN 10088 (AISI 304) |
| Membrane | Butyl |
| Tank cover | POM - POLYACETAL |
| Membrane cap | POM - POLYACETAL |
| Non-return valve | POM - POLYACETAL |
| Plug | Cr-Ni steel 1.4305 EN 10088 (AISI 303) |
| Mechanical seal | Carbon - Ceramic - NBR |
| Pump Model | Motor | Impeller Material | |
| META | 1.35kW | 1.8HP | AISL |
